12 channels rated at 50 watts into 8 ohms
- 75 watts per channel into 4 ohms
- 100 watts x6 bridged mono at 8 ohms
- 12 channels (6 stereo zones)
- 12 independent level controls
Features
- IR Remote control
- 2 Line Bus inputs
- 2 Line Bus outputs
- Independent inputs for all 8 channels
- Master level controls for Bus 1 and 2
- Phoenix-style speaker connectors
- Optical input
- Rear mounted treble and bass controls
- High efficiency class D topologies
- Black anodized brushed aluminum faceplate
- Bridgeable outputs
- OTP Protection (over temperature protection)
- OCP Protection (over current protection)
- LED status indicator lights
- Manual, auto, or triggered on/off
- Rack mountable (Rack ears included)
- Stereo line outputs
- 2 year warranty
Specifications
- Input Sensitivity: Variable, .350mV to full output with all level controls at max
- Frequence response: 20Hz to 20Hz
- Channel Crosstalk: 60 dB
- Less than 0.2% THD into 8 ohms at rated power
- S/N Ratio: 100 dB A-weighted
