2 Channels rated at 150 watts into 8 ohms
- 225 watts RMS per channel @ 4 ohms
- Bridge Output: 450 Watts @ 8 ohms
Features
- 5-Way Binding Posts
- A/B Speaker selector
- Auto Signal Sensing Power On
- Dual Auto-Switching Inputs
- Dual-differential error amplifiers
- Front panel balance and volumen controls
- Front panel diagnostic LEDS
- High level inputs
- Line 2 Auxiliary output
- Rear independent left/right master level controls
- Rear mounted treble and bass controls
- Triple-Darlington Power Amplifier Stages
- Rack mountable (Rack ears included)
Specifications
- Input Sensitivity: Variable, .350mV to 2.8V for rated power at 8 ohms
- Frequence response: 10Hz to 50kHz
- Channel Crosstalk: 70 dB
- Less than 0.2% THD into 8 ohms at rated power
- S/N Ratio: 100 dB A-weighted
