5 CHANNEL D-CLASS COMPACT POWER AMPLIFIER WITH BUILT-IN 5.0 LOSSLESS BLUETOOTH
SKU: BL-BPA-M605BT
Brand part number: BPA-M605BT
Brand: Blaupunkt


    Eta:

      Ship to
      *
      *
      Shipping Method
      Name
      Estimated Delivery
      Price
      No shipping options

      Channels: 5/4/3
      Built-in Bluetooth: 5.0 Lossless
      Max Power Output: 2400 Watts
      4 x 180W + 1 x 600W @ 2 Ohms
      4 x 120W + 1 x 400W @ 4 Ohms
      2 x 300W @ 2 Ohms + 1 x 800W @ 1 Ohm – Bridged
      (W x H x L) 3.9″ x 1.9″ x 10.6″


      Class D
      Frequency Response: 10 Hz – 20 kHz (Ch 1-4)
      Frequency Response: 10 Hz – 250 Hz (Ch 5)
      Crossover Frequency: 35 Hz – 250 Hz
      Crossover Slope: 8 – 10 dB/Oct

      Gain Adjust: 400mV – 12V
      S/N Ratio: > 90 dB
      THD: <= 0.05%
      Voltage Supply: 11 – 15 VDC

      Channels: 5/4/3
      Built-in Bluetooth: 5.0 Lossless
      Max Power Output: 2400 Watts
      4 x 180W + 1 x 600W @ 2 Ohms
      4 x 120W + 1 x 400W @ 4 Ohms
      2 x 300W @ 2 Ohms + 1 x 800W @ 1 Ohm – Bridged
      (W x H x L) 3.9″ x 1.9″ x 10.6″


      Class D
      Frequency Response: 10 Hz – 20 kHz (Ch 1-4)
      Frequency Response: 10 Hz – 250 Hz (Ch 5)
      Crossover Frequency: 35 Hz – 250 Hz
      Crossover Slope: 8 – 10 dB/Oct

      Gain Adjust: 400mV – 12V
      S/N Ratio: > 90 dB
      THD: <= 0.05%
      Voltage Supply: 11 – 15 VDC

      Products specifications
      Master Pack5
      Unit of MeasureEACH
      Warranty1 YEAR
      FF Level100
      Products specifications
      Master Pack5
      Unit of MeasureEACH
      Warranty1 YEAR
      FF Level100
