RADIO
Type of tuner Blaupunkt receiver
World tuner (switchable) Europe, OIRT, Americas, Japan
Wave bands FM 1, 2, 3, AM 1, 2
Radio Data System (RDS) AF, CT, EON, PS, PTY, TA, TP, RT
Travelstore Yes (FMT, AMT)
Band Scan Yes
Search via frequency Yes
Station memory 30
Sensitivity lo/dx
Frequency response (Hz) -3dB 30 – 15.000
DISPLAY
Technology Digital
Type TFT Capacitive
Screen size 6.75″
Resolution 800 x 480 pixels
Touchscreen Yes
Brightness adjustable Yes
Display switch off Yes (off after 10 or 20sec selectable)
Clock display 24 / 12 hours
Date display Yes
Wallpaper options Yes
Wallpaper / Picture upload Yes
Radio system languages English, Spanish, Portuguese
NAVIGATION
Navi-ready –
ANDROID AUTO CONNECTION
Type USB and Wireless
Learn more at: https://www.android.com/auto
APPLE CARPLAY CONNECTION
Type USB and Wireless
Learn more at: https://www.apple.com/ios/carplay
DATA CARRIER
DVD –
VCD –
CD –
Type disc-drive –
Shock proof memory –
Frequency response (Hz) -3dB 20 – 20.000
USB-removable storage USB 2.0 compatible
iPod / iPhone control via USB Yes
Memory cards –
Formatting USB FAT, FAT 16, FAT 32
MEDIA PLAYER
Video playback formats AVI, 3GP, M4V, MOV, MP4, MPG, TS, VOB, WMV, QT, FLV, MKV
Dolby Digital 2.0
DivX® video format –
Picture playback formats JPEG, JPG
Audio formats USB APE, FLAC, MP3, WAV, WMA, OGG
Audio formats Disc –
MP3 Title display ID3-tag (versions 1 and 2),
file/folder names
MP3 folder/file browsing Yes (w/o track interruption)
MP3 file search Yes (by track number)
Criteria browsing –
Mix Yes (all, folder)
Repeat Yes (all, folder, track)
Fast forward / fast rewind Yes (via progress bar)
CD text –
Number of files up to 10.000 on MSD
Bit rate MP3 32 – 320 kBit/s
Bit rate WMA 32 – 192 kBit/s
Variable bit rates Yes
BLUETOOTH
Supported version Bluetooth 4.2
Supported profiles HFP, PBAP, A2DP, AVRCP
Audio streaming Yes
Pairing (number of devices) 5
Pairing code 1234 (default, changeable)
Hands-free calling via micro + radio speakers
Microphone 2 (built-in + external rear micro)
Key functions accept / hang up / reject call
Phone book access Yes (up to 2.000 entries by phone)
History call lists Yes (missed, dialled, received calls)
Auto synchronisation –
2nd call handling – (call wait / call hold)
EQUALIZER
Number of bands 10
Model parametric
Type analogue
Variable subwoofer gain Yes (24 steps)
Variable subwoofer frequency –
Loudness Yes
Dynamic sound –
Sound presets Rock, pop, classic
Balance / fader Yes / Yes (+/- 20 steps)
Source specific volume Radio, Bluetooth, USB, AV-IN
AMPLIFIER
Number of channels 4
Max. power 4 x 45 Watt
Sinus power at 14.4 V 4 x 20 Watt
INPUTS
Antenna 1 (Radio)
USB 2 Rear (A-type) Memory card reader –
Audio / Video (analogue) Rear A/V (RCA Type)
Rear view camera Yes
Reverse gear Yes
Handbrake Yes
External hand-free microphone Yes (3.5 mm jack, rear)
IR remote control Yes (front panel)
Steering wheel remote control Yes (SWC, rear, analogue, 3.5 mm jack, programmable via menu)
Power supply Yes (cable set with ISO)
OUTPUTS
Video out –
Video out sources –
4-channel preamp out Yes (RCA, 2V)
Subwoofer Yes (RCA)
Audio channels 4
GENERAL
Installation 2-DIN slot
Operating voltage 10,8 – 16V
Weight ca. 2,20 kg
Depth (incl. panel + connector) ca. 175,0 mm
Depth (installation depth) 165 mm
Width 180 mm
Height 100 mm
Front panel fixed
Colour piano black
Illumination Keys: white
Demo mode –
Theft protection –
ACCESSORIES INCLUDED IN DELIVERY
User manual Yes 2 languages:
English, Spanish, Portuguese
IR remote control Yes
External hands-free micro –
Mounting material Yes
Connector cable sets Yes Power
Yes Speakers
Yes Camera (RCA)
Yes Reverse, brake, P-control (cable)
Yes SWC (3.5 mm jack)
