| General Specs | Amp Topology | Full Range, Class D |
| | Power Supply Type | MOSFET Power Supply |
| Performance Specs | Total Power Output | 2200 Watts |
| | Peak Power @ 2 Ω | 300 Watts x |
| | Peak Power @ 4 Ω | 150 Watts x |
| | Bridged Power @ 4 Ω | 600 Watts x |
| | RMS Power @ 2 Ω | 225 Watts x |
| | RMS Power @ 4 Ω | 113 Watts x |
| | Bridged RMS Power @ 4 Ω | 450 Watts x |
| | Speaker Impedance | 2 to 8 Ω |
| | T.H.D. (Total Harmonic Distortion) | 0.01 % |
| | Channel Separation ≥ | 90 dB |
| | Frequency Response | 9 Hz to 50 " " kHz ±1 dB |
| Connections, Controls, and Processing | RCA Inputs | 6 Channel |
| | High Level Inputs | ✔ |
| | Low Pass Filter | 50 Hz to Hz |
| | High-Pass Filter | Variable " " Hz " " Hz |
| | Bass Boost | Variable " " " " " " dB |
| | Subwoofer Level Control | ✔ |
| | Input Sensitivity Switch | ✔ |
| | Thermal/Overload/Short Protection | ✔ |
| Extra Features | | External fuse and fuse holder not included. |
| Measurement | Length | 4.57 " |
| | Width | 11.34 " |
