SPEAKER SIZE - 6X9"
SPEAKER TYPE - CO AXIAL
OHMS (PER COIL) - 2Ω
NUMBER OF VOICE COILS - SINGLE
CONE MATERIAL - CARBON FIBER
DIAPHRAGM MATERIAL - TITANIUM
BASKET MATERIAL - FIBREGLASS REINFORCED POLYMER
MAGNET TYPE - NEODYMIUM
SURROUND MATERIAL - RUBBER
WATER RESISTANCE -
VOICE COIL DIAMETER - INCH (MM) - 2"
THIELE/SMALL PARAMETERS
SENSITIVITY (1W/1M): 94
RE (Ω) [SERIES]: 2
QMS: 3.759
QES: 0.471
QTS: 0.419
FS (HZ): 69
VAS (L): 23.014
CMS (MM/N): 0.343
MMS (G): 15.599
SD (M2): 217.28
BL (T*M): 5.348
XMAX (MM): 3.25
POWER HANDLING RMS: 150
POWER HANDLING MAX: 450
MOUNTING DEPTH: IN.(MM):3.10" (78.81MM)
CUT OUT DIAMETER IN.(MM):8.51" (216.03MM)
OVER ALL DIAMETER IN.(MM):9.46" (240.29MM)
OVER ALL HEIGHT IN.(MM):3.58" (90.81MM)
