Powersports All-Weather Full Range Class D 4-Channel Amplifier 200W RMS x 4 @ 2Q

SKU: MX-PS800.4

Brand part number: PS800.4

Brand: MTX

Be the first to review this product

Unit of Measure: EACH

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Compact Powerhouse

At just under 10 inches wide, the PS800.4 fits easily into tight installations while still delivering 200 watts RMS per channel at 2Ω. Its efficient Class-D circuit design means you get big sound without putting unnecessary strain on your electrical system.

Built for the Outdoors

IP67-rated against dust and water, the PS800.4 is engineered to handle the harshest environments. From desert trails to muddy backroads, stainless steel hardware and a sealed chassis keep it performing no matter where you ride.

Smart Protection & Reliability

LED status indicators and built-in safeguards against thermal overload, short circuits, and voltage fluctuations ensure reliable performance every time. With CTA-2006-D certification, the PS800.4 delivers honest power that lives up to the numbers.

Dimensions & Details

Dimensions

A - Length:
9 ⁵⁄₈” (244mm)
B - Width:
4 ¹¹⁄₁₆" (119mm)
C - Depth:
2" (51mm)

Features

Reliable and Efficient Full Range Class-D Circuit Design
IP67 Rated Against Water and Dust
Small Size Footprint for Easy Installation
Surface Mount Component Technology
Power and Protection LED Light Status Indicators
Short, Thermal, and Under / Over Voltage Protection
DC Offset Auto Turn On
10V High-Level Audio Input Compatibility

Ratings

IP67 Rated
CEA2006D compliant
RECOMMENDED FUSE RATING: 100A

SPECIFICATIONS

Description: Full Range
Topology: Class D
2Ω RMS Power Output: 200W x 4 Channels
4Ω RMS Power Output: 100W x 4 Channels
4Ω RMS Bridged Power Output : 400W x 2 Channels
THD: < 0.8%
Signal to Noise Ratio: > 98dB
Frequency Response: 20Hz - 20kHz
Crossover: 50Hz - 500Hz
Maximum Input Signal: 10V
Warranty Period: 24 months from date of purchase
